KDD Doosan
| KDD Series -- Powered by DOOSAN Engine | Three-phase 50Hz | ||||||||||
| Genset Model | Prime Power | Standby Power | Engine | Alternator | Control System | Fuel consumption 75%(L/H) | Dimension(mm) | ||||
| KW | KVA | KW | KVA | Doosan | Stamford | Knoxgen | Open type | Soundproof type | |||
| KDD69E | 50 | 62.5 | 55 | 69 | SP344CB | S1L2-Y1 | L2L1D-C4 | Standard: 6120 Auto control system | 10.3 | 1860*900*1400 | 2280*950*1510 |
| KDD88E | 64 | 80 | 70 | 88 | SP344CC | UCI224G | L2L1D-E4 | 13.5 | 1860*900*1400 | 2280*950*1510 | |
| KDD165E | 120 | 150 | 132 | 165 | DP086TA | UCI274F | L3L1D-E4 | 26.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD185E | 134 | 168 | 148 | 185 | P086TI-1 | UCI274G | L3L1D-G4 | 27.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD220E | 160 | 200 | 176 | 220 | P086TI | UCI274H | L3L1D-J4 | 32.0 | 2250*1020*1850 | 3450*1130*2130 | |
| KDD250E | 180 | 225 | 200 | 250 | DP086LA | UCDI274J | L3L1D-K4 | 37.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD300E | 220 | 275 | 240 | 300 | P126TI | S4L1D-D4 | L4L1D-B4 | 44.0 | 3000*1100*1800 | 3800*1500*2100 | |
| KDD330E | 240 | 300 | 264 | 330 | P126TI-II | S4L1D-D4 | L4L1D-B4 | 47.0 | 3000*1100*1800 | 3800*1500*2100 | |
| KDD400E | 292 | 365 | 320 | 400 | DP126LB | S4L1D-E4 | L4L1D-F4 | 57.0 | 3000*1100*1850 | 3950*1550*2150 | |
| KDD440E | 320 | 400 | 352 | 440 | P158LE | S4L1D-F4 | L4L1D-G4 | 65.0 | 3150*1350*1900 | 3950*1600*2300 | |
| KDD500E | 360 | 450 | 400 | 500 | DP158LC | S4L1D-G4 | L5L1D-A4 | 73.0 | 3080*1460*2080 | 3950*1600*2300 | |
| KDD580E | 420 | 525 | 464 | 580 | DP158LD | S5L1D-C4 | L5L1D-C4 | 83.0 | 3080*1460*2080 | 3950*1600*2300 | |
| KDD633E | 460 | 575 | 506 | 633 | DP180LA | S5L1D-D4 | L5L1D-D4 | 94.0 | 3450*1400*2200 | 4250*1600*2230 | |
| KDD688E | 500 | 625 | 550 | 688 | DP180LB | S5L1D-E4 | L5L1D-E4 | 104.0 | 3450*1400*2200 | 4250*1600*2230 | |
| KDD760E | 550 | 688 | 608 | 760 | DP222LB | S5L1D-G4 | L5L1D-F4 | 109.0 | 3800*1550*2200 | 4900*2000*2450 | |
| KDD825E | 600 | 750 | 660 | 825 | DP222LC | S5L1D-H4 | L6L1D-A4 | 119.0 | 4000*1550*2200 | 4900*2000*2450 | |
| KDD825CE | 600 | 750 | 660 | 825 | DP222CA | S5L1D-H4 | L6L1D-A4 | 133.0 | 4000*1550*2200 | 5200*2200*2550 | |
| KDD880E | 640 | 800 | 704 | 880 | DP222CB | S6L1D-C4 | L6L1D-B4 | 145.0 | 4000*1550*2200 | 5200*2200*2550 | |
| KDD1000E | 730 | 913 | 800 | 1000 | DP222CC | S6L1D-D4 | L6L1D-C4 | 147.0 | 4000*1550*2200 | 5200*2200*2550 | |
| KDD Series -- Powered by DOOSAN Engine | Three-phase 60Hz | ||||||||||
| Genset Model | Prime Power | Standby Power | Engine | Alternator | Control System | Fuel consumption 75%(L/H) | Dimension(mm) | ||||
| KW | KVA | KW | KVA | Doosan | Stamford | Knoxgen | Open type | Soundproof type | |||
| KDD80E6 | 58 | 72.5 | 64 | 80 | SP344CB | S1L2-Y1 | L2L1D-C4 | Standard: 6120 Auto control system | 12.2 | 1860*900*1400 | 2280*950*1510 |
| KDD100E6 | 73 | 91.3 | 80 | 100 | SP344CC | UCI224G | L2L1D-E4 | 15.4 | 1860*900*1400 | 2280*950*1510 | |
| KDD200E6 | 144 | 180 | 160 | 200 | DP086TA | UCI 274F | L3L1D-F4 | 30.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD206E6 | 150 | 188 | 165 | 206 | P086TI-1 | UCI 274F | L3L1D-F4 | 32.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD250E6 | 182 | 227 | 200 | 250 | P086TI | UCI 274H | L3L1D-J4 | 38.0 | 2250*1020*1850 | 3450*1130*2130 | |
| KDD275E6 | 200 | 250 | 220 | 275 | DP086LA | UCDI274J | L3L1D-K4 | 42.0 | 2500*1050*2000 | 3450*1130*2130 | |
| KDD344E6 | 250 | 313 | 275 | 344 | P126TI | S4L1D-C4 | L4L1D-B4 | 52.0 | 3000*1100*1800 | 3800*1500*2100 | |
| KDD385E6 | 275 | 344 | 308 | 385 | P126TI-II | S4L1D-D4 | L4L1D-B4 | 56.0 | 3000*1100*1800 | 3800*1500*2100 | |
| KDD440E6 | 320 | 400 | 352 | 440 | DP126LB | S4L1D-E4 | L4L1D-E4 | 64.0 | 3000*1100*1850 | 3950*1550*2150 | |
| KDD500E6 | 360 | 450 | 400 | 500 | P158LE | S4L1D-F4 | L4L1D-F4 | 75.0 | 3150*1350*1900 | 3950*1600*2300 | |
| KDD572E6 | 416 | 520 | 458 | 572 | DP158LC | S4L1D-G4 | L5L1D-A4 | 83.0 | 3080*1460*2080 | 3950*1600*2300 | |
| KDD625E6 | 454 | 568 | 500 | 625 | DP158LD | S5L1D-D4 | L5L1D-B4 | 93.0 | 3080*1460*2080 | 3950*1600*2300 | |
| KDD695E6 | 504 | 630 | 556 | 695 | DP180LA | S5L1D-E4 | L5L1D-C4 | 107.0 | 3450*1400*2200 | 4250*1600*2230 | |
| KDD750E6 | 550 | 688 | 600 | 750 | DP180LB | S5L1D-E4 | L5L1D-D4 | 114.0 | 3450*1400*2200 | 4250*1600*2230 | |
| KDD825E6 | 600 | 750 | 660 | 825 | DP222LA | S5L1D-F4 | L5L1D-F4 | 120.0 | 3800*1550*2200 | 4900*2000*2450 | |
| KDD875E6 | 635 | 794 | 700 | 875 | DP222LB | S5L1D-G4 | L6L1D-A4 | 128.0 | 3800*1550*2200 | 4900*2000*2450 | |
| KDD927E6 | 674 | 843 | 742 | 927 | DP222LC | S5L1D-H4 | L6L1D-A4 | 134.0 | 4000*1550*2200 | 4900*2000*2450 | |
| KDD950E6 | 690 | 863 | 760 | 950 | DP222CA | S6L1D-C4 | L6L1D-A4 | 148.0 | 4000*1550*2200 | 5200*2200*2550 | |
| KDD1025E6 | 750 | 938 | 820 | 1025 | DP222CB | S6L1D-D4 | L6L1D-B4 | 160.0 | 4000*1550*2200 | 5200*2200*2550 | |
| KDD1125E6 | 800 | 1000 | 900 | 1125 | DP222CC | S6L1D-D4 | L6L1D-C4 | 167.0 | 4000*1550*2200 | 5200*2200*2550 | |
