KDK KUBOTA
| KDK Series -- Powered by KUBOTA Engine | Three-phase 50Hz | ||||||||||
| Genset Model | Prime Power | Standby Power | Engine | Alternator | Control System | Fuel cons 75%(L/H) | Dimension(mm) | ||||
| KW | KVA | KW | KVA | KUBOTA | STAMFORD | Knoxgen | Open type | Soundproof type | |||
| KDK11S | 8 | 10 | 8.8 | 11 | D1105-E2BG-CHN-1 | S0L1-H1 | L1L1D-B4 | Standard:6120 auto control system | 1.5 | 1200*700*1100 | 1600*800*1100 |
| KDK14S | 10 | 13 | 11 | 14 | V1505-E2BG-CHN-1 | S0L1-L1 | L1L1D-C4 | 1.9 | 1200*700*1100 | 1600*800*1100 | |
| KDK17S | 12 | 15 | 13.6 | 17 | D1703-E2BG-CHN-1 | S0L1-P1 | L1L1D-D4 | 2.2 | 1300*700*1100 | 1700*800*1100 | |
| KDK22S | 16 | 20 | 17.6 | 22 | V2203-E2BG-CHN-1 | S0L2-G1 | L1L1D-E4 | 3.0 | 1400*700*1100 | 1700*800*1100 | |
| KDK28S | 20 | 25 | 22 | 28 | V2003-T-E2BG-CHN-1 | S0L2-M1 | L1L1D-F4 | 3.7 | 1400*700*1100 | 1800*800*1150 | |
| KDK33S | 24 | 30 | 26.4 | 33 | V3300-E2BG2-CHN-1 | S0L2-P1 | L1L1D-G4 | 4.4 | 1500*800*1250 | 2000*850*1300 | |
| KDK37S | 27 | 34 | 30 | 37 | V3300-T-E2BG2-CHN-1 | S1L2-J1 | L1L1D-H4 | 5.0 | 1500*800*1250 | 2000*850*1300 | |
| KDK Series -- Powered by KUBOTA Engine | Three-phase 60Hz | ||||||||||
| Genset Model | Prime Power | Standby Power | Engine | Alternator | Control System | Fuel cons 75%(L/H) | Dimension(mm) | ||||
| KW | KVA | KW | KVA | KUBOTA | STAMFORD | Knoxgen | Open type | Soundproof type | |||
| KDK12S6 | 9 | 11.3 | 10 | 12 | D1105-E2BG-CHN-1 | S0L1-H1 | L1L1D-B4 | Standard: 6120 auto control system | 1.7 | 1200*700*1100 | 1600*800*1100 |
| KDK18S6 | 13 | 16 | 14 | 18 | D1703-E2BG-CHN-1 | S0L1-P1 | L1L1D-C4 | 2.4 | 1300*700*1100 | 1700*800*1100 | |
| KDK28S6 | 20 | 25 | 22 | 28 | V2203-E2BG-CHN-1 | S0L2-M1 | L1L1D-E4 | 3.7 | 1400*700*1100 | 1700*800*1100 | |
| KDK39S6 | 28 | 35 | 31 | 39 | V3300-E2BG-CHN-1 | S0L2-P1 | L1L1D-F4 | 5.2 | 1500*800*1250 | 2000*850*1300 | |
